Schacht Spindle Company

Beater Support Kit for Standard Floor Looms

Schacht Spindle Company  |  SKU: R-16-920020

Includes one metal beater support and hardware to attach to beater side—does not include hardware to attach to the loom. Each beater side requires one beater support.

Fits all Standard Floor Looms.


Regular price $16.00

Lead Time

  • Most orders will ship within 2 weeks. Orders for floor looms and spinning wheels will ship within 9 weeks.

Read before ordering

You'll need to remove the beater from the loom to install this kit.

How to install

Follow the instructions given in the assembly manual. You can find all Schacht assembly manuals on this page.

The assembly manual for flat-packed (international) looms explains how to install an assembled beater—follow these steps in reverse to remove the beater.

To replace the beater support:

  1. Remove the hardware attaching the support to the inner face of the beater side. Remove the old beater support.
  2. Set the new beater support in position on the inner face of the beater side, aligning all holes. From the outer face of the beater side, insert a carriage bolt through each hole. From the inner side, add a washer to the bolt shaft, then add a hex nut. Tighten the hex nuts as much as possible.

Replace the assembled beater on the loom, following instructions in the assembly manual for flat-packed looms.
